    DC031 3.5*1.3MM power adapter connector DC-031 4 pin SMD SMT Power Jack socket

    DC031 3.5*1.3MM power adapter connector DC-031 4 pin SMD SMT Power Jack socket Featured Image
    • DC031 3.5*1.3MM power adapter connector DC-031 4 pin SMD SMT Power Jack socket

    Short Description:

    DC031 3.5*1.3MM power adapter connector DC-031 4 pin SMD SMT Power Jack socket

    Product info
    Item name: DC socket
    Model No.: DC031
    Current: 0.5A
    Voltage: 30V
    Operating force: 250gf
    Lifetime: 5,000 cycles
    Operating temp.range: -20~+50℃


    Product Detail

    Product Tags
