    single row 5.8mm push button key switch high-head 3 pin self latching momentary switch

    single row 5.8mm push button key switch high-head 3 pin self latching momentary switch Featured Image
    • single row 5.8mm push button key switch high-head 3 pin self latching momentary switch
    • single row 5.8mm push button key switch high-head 3 pin self latching momentary switch
    • single row 5.8mm push button key switch high-head 3 pin self latching momentary switch
    • single row 5.8mm push button key switch high-head 3 pin self latching momentary switch
    • single row 5.8mm push button key switch high-head 3 pin self latching momentary switch

    Short Description:



    product name Self-resetting switch
    model number 5.8 Self-resetting switch
    Rating Value DC30V 0.1A
    Work Temperature Range -10℃-+70℃
    Insulation impedance 100 MΩ Min
    Contact impedance 100 mΩ Max
    Operating force 180±80gf
    Full stroke 2.0mm±0.2mm
    Run type Self-resetting
    Mechanical life 10000 cycles

    Product Detail

    Product Tags

    H6445063583aa478f808bf64292c30cdeR.avif
