HDMI gold Assembly Usb Charging Connector Por
Quick Details
- Place of Origin:
-
Guangdong, China
- Brand Name:
-
SHOUHAN
- Model Number:
-
Mini h d m i connector
- Type:
-
wide varieties
- Application:
-
wide application
- Gender:
-
Female
- Pins:
-
16p, 14P, 4p, 5P, 24P, 6P
- Product name:
-
Assembly H D M I Usb Charging Connector Port
- Certificate:
-
SGS ROHS
- Voltage rating:
-
0.5A Max
- Rating current:
-
40V AC/Max
- CONTACT RESISTANCE:
-
10m Ohms Max
- Insulation resistance:
-
100MΩ/Min
- Dielectric withstanding voltage:
-
AC 500V Min(for 1 minute)
- Operation temperature range:
-
-25℃~85℃
- Insertion force:
-
4.5KGF MAX
- Withdrawal Force:
-
1.0KGF Min
