    High quality DC-015 dc power jack socket

    High quality DC-015 dc power jack socket Featured Image
    • High quality DC-015 dc power jack socket

    Short Description:

    Product info
    Item name: DC socket
    Model No.: DC015
    Current: 0.5A
    Voltage: 30V
    Operating force: 250gf
    Lifetime: 5,000 cycles
    Operating temp.range: -20~+50℃
    Package Type:

    High quality DC-015 dc power jack socket
Packaging Details
High quality   dc power jack socket
1: Neutral packing : plastic bag for goods+paper box +carton
2: Upon customers' request, but the price is different with neutral packing
3: Carton size: be confirmed by both sides
4: 200 pcs/box
Shipped in 5~7days after payment
