12MM Mini 2pin Dome Button OFF-(ON) Ball Shape Momentary Waterproof Plastic Motorcycle Push Button Switch
12MM Mini 2pin Dome Button OFF-(ON) Ball Shape Momentary Waterproof Plastic Motorcycle Push Button Switch
Push Button Switch Main technical parameter
1) . Mounting Hole Size :Φ12mm
2) . Switch Rating:3A/250VAC
3) . Contact Configuration:1NO1NC
4) . Operation Type: Momentary, Latching
5) . The Crust Material:Stainless Steel
6) . Protection Degree:IP40, ( IP65 Can be made to order )
Function:
The switch is OFF-(ON) momentary function, when you push and hold, switch ON, when you release, switch OFF.
Emergency stop button usage:
For emergency stop in the industry with the striking red mushroom plug. Widely used to control electromagnetic start, contactor, relay and other automatic control electric circuits.
