3.7 mm Tactile Switch Przelaczniki tact Height 0.35mm SMD 4 PIN DC12V 0.05A SKRWAEE030 SKRWADE030

Short Description:

Product introduction
Item name: membrane tactile switch
Model No.: TS373735A
Rating: 500mA.12V DC
Dieletric strength: 250V AC for 1 min
Contact resistance: 500mΩ max
Operating temperature: -20℃~+70℃
Lifetime: 50,000 cycles min
Operating force: 180gf/250gf
Travel: 0.15±0.05mm
Uage:
- For operating various mobile devices
- For operating various devices that require high density mounting such as mobile phones,communication equipment.


Product Detail

Product Tags



FEATURES :

1, 100000 cycle life or customizable 2, Meet ROHS and REACH standards; 3, Self lock or Non lock pushbutton switch 4, Terminal & Travel customizable 5 , SPST

6, SMT

APPLICATIONS :

1 , Home Appliance

2, Consumer electronics
3, Medical equipment
4, Electronic toys
5, Computer/peripherals
6, , Testing / instrumentation
