RJ45 male connector STP Cat5 Cat6 Cat7 8P8C UTP Network Modular Plug

Short Description:

product name Rj45 Connector male
model number RJ45-M8P-DS-1.2MM
Working current 0.75A
Operating voltage 150V
Service temperature -20℃~+60℃
Contact resistance 30mΩ Max
Insulation resistance 500MΩ Min
Withstand voltage test 1000V AC/minute
Insertion force 133N
Pullout force 10N
