    MX16-AAB-01 Series waterproof IP67 Electrical Miniature Micro switch 3pin

    MX16-AAB-01 Series waterproof IP67 Electrical Miniature Micro switch 3pin Featured Image
    • MX16-AAB-01 Series waterproof IP67 Electrical Miniature Micro switch 3pin
    • MX16-AAB-01 Series waterproof IP67 Electrical Miniature Micro switch 3pin
    • MX16-AAB-01 Series waterproof IP67 Electrical Miniature Micro switch 3pin
    • MX16-AAB-01 Series waterproof IP67 Electrical Miniature Micro switch 3pin
    • MX16-AAB-01 Series waterproof IP67 Electrical Miniature Micro switch 3pin

    Short Description:

    product name Waterproof Micro Switch
    Product number MX16-AAB-01
    Support customization yes
    load life 50000 cycles
    operating force 20-100gf
    Insulation resistance DC 500V 100MΩ Min
    Operating  Temperature -40℃~125℃
    protection degree IP67
    Switched function ON-(ON)
    contact resistance 50 MΩ Max
