KFC-VT-224 3.5*4.7 Limit switch Micro detection 103 reset limit switch LY-TS-10 Switch

Short Description:

Product description
Item name: Micro switch with cable
Model No.: KFC-VT-224
Category: 4 pin
Life:50,000 cycles


Product Detail

Product Tags



Product Name Micro switch with cable
Size 3.5*4.7mm
Max. Current 0.2A
Max. Voltage 60V
Operating Temperature -40℃-+70℃
operating force 20-35gf
Category 4 pin
Withstand Voltage AC250V(50Hz)min
Life 50,000 cycles
Contact Resistance 0.05Ω Max
Insulation Resistance 100mΩ Max Min

Micro switch in frequent exchange circuit device for automatic control and safety protection etc., are widely used in household electric appliances electronics instrument of mine power system electrical equipment, as well as military fields such as aerospace ship missile tanks, has been widely used in the above areas, switch are small, but plays an irreplaceable role At present, the micro switch on the domestic market according to the different use requirements, the mechanical life of the switch has 3W times to 1000W times, generally 10W 20W 50W 100W 300W 500W 800W times, the general use of beryllium bronze tin bronze Stainless steel wire is used to make reeds. ALPS in foreign countries can make reeds up to 1000W times. Their reeds are made of rare metal titanium, which can be used in computer mouse, car mouse, car electronic products, communication equipment, military products, test instruments, gas water heater, gas stove, small household appliances, microwave oven, electric cooker, floating ball equipment and supporting medical instruments 24 hour timers for building automation power tools and general electrical and radio equipment详情-01 主图-04 详情-02 2 4 5 6 7 8 9 10 11 12 13

14
