    DB-F-1 139 3Pin female connector industrial AC power socket jack 250V 10A

    DB-F-1 139 3Pin female connector industrial AC power socket jack 250V 10A Featured Image
    • DB-F-1 139 3Pin female connector industrial AC power socket jack 250V 10A
    • DB-F-1 139 3Pin female connector industrial AC power socket jack 250V 10A
    • DB-F-1 139 3Pin female connector industrial AC power socket jack 250V 10A

    Short Description:

    Product: AC Socket
    Model No.: DB-F-1 139
    Rating: 250VAC 10A
    Pin: 3 pin


    Product Detail

    Product Tags





    Product Name AC Socket
    Size 5.8*2.5 cm
    Max. Current 10A
    Max. Voltage 250V AC
    Application Industrial
    Insulation resistance 100MΩ 500V DC/1 Min
    Model DB-F-1 139
    Product Usage Various power sockets
    Withstand Voltage 2500V(50-60Hz)/5S

    AC power socket is mainly used for power protection, household appliances, medical equipment, beauty equipment, communication equipment, office equipment, electronic toys, multimedia players and so on. The products are widely used, mature production technology, stable performance and high cost performance.主图-05 主图-01 主图-06 主图-02 详情-06 2 4 5 6 7 8 9 10 11 12 13 14
