    AF90 degree usb connector 2.0 4pin USB A Type Female Socket connector DIP Desktop Laptop USB jack Flat port AF SMT straight usb connector

    AF90 degree usb connector 2.0 4pin USB A Type Female Socket connector DIP Desktop Laptop USB jack Flat port AF SMT straight usb connector Featured Image
    • AF90 degree usb connector 2.0 4pin USB A Type Female Socket connector DIP Desktop Laptop USB jack Flat port AF SMT straight usb connector
    • AF90 degree usb connector 2.0 4pin USB A Type Female Socket connector DIP Desktop Laptop USB jack Flat port AF SMT straight usb connector

    Short Description:

    Product description
    Item name: A female 90 degree DIP USB connector
    Rating: DC 30V 0.2A
    Insulation resistance: ≥1000mΩ min. 500V DC
    Dielectric strength: 250V AC for 1 min
    Contact resistance: ≤50mΩ
    Insertion force: ≤35N
    Extraction force: ≥10N
    Usage:
    -Mainly used in high end industries,such as digital camera interface products,computer accessories,electronic toys,mobile phone charging interface and other products need to charge.

    Product Detail

    Product Tags

    Quick Details

    Place of Origin:
    Guangdong, China
    Brand Name:
    OEM/SHOUHAN
    Model Number:
    Usb 2.0 female connector
    Type:
    usb
    Application:
    USB
    Gender:
    Female
    Product name:
    AF 90degree DIP usb connector 2.0
    Rated voltage:
    DC 30V
    Rated current:
    1.0A
    Contact Resistance:
    ≤30mΩ
    Insulation resistance:
    ≥100mΩ
    Test voltage:
    DC500V
    Actuating Force:
    5~35N
    Useful life:
    1500 cycles
    Salt Spray Test:
    8H
