HOT SALE USB Connector a Male 180 Degree Black Acrylic 4 Pin USB Socket

Short Description:

Product description

Item name: A male USB connector 180 degree

Rating: DC 30V 0.2A

Insulation resistance: ≥1000mΩ min. 500V DC

Dielectric strength: 250V AC for 1 min

Contact resistance: ≤50mΩ

Insertion force: ≤35N

Extraction force: ≥10N

Usage:

-Mainly used in high end industries,such as digital camera interface products,computer accessories,electronic toys,mobile phone charging interface and other products need to charge.

Send email to us

Product Detail

Product Tags

Quick Details

Place of Origin:: Guangdong, China

Brand Name:: OEM/SHOUHAN

Model Number:: USB Connector smd

Type:: usb

Application:: USB

Gender:: Male

Pins:: 4p

Product name:: USB Connector a Male 180 Degree Black Acrylic 4 Pin USB Socket

Item:: USB CONNECTOR A type

Connector type:: male Terminals

Color:: Silver/Black

Pin:: 4pin

Insulation Resistance:: 100M Ohm/Min

Dielectric withstand voltage:: 500VAC/min

Contact resistance:: 40m Ohm Max

Operating force:: 1.02kgf-3.57kgf

Life:

5,000 cycles

Product Name	USB Connector a Male 180 Degree Black Acrylic 4 Pin
Model	A male SMD
Life	5,000 times
Operation strenght	1.02kgf-3.57kgf
Temperature	-20℃—+70℃
Dielectric strenght	AC 250V
Rated current	1A
