USB connector micro male seat solder wire type usb socket with voltage rating 2A

Short Description:

Product description

Item name: Type C male USB connector

Rating: DC 30V 2A

Insulation resistance: ≥1000mΩ min. 500V DC

Dielectric strength: 250V AC for 1 min

Contact resistance: ≤50mΩ

Insertion force: ≤35N

Extraction force: ≥10N

Usage:

-Mainly used in high end industries,such as digital camera interface products,computer accessories,electronic toys,mobile phone charging interface and other products need to charge.

Send email to us

Product Detail

Product Tags

Quick Details

Place of Origin:: Guangdong, China

Brand Name:: OEM/SHOUHAN

Model Number:: USB Connector smd

Type:: usb

Application:: USB

Gender:: Male

Pins:: 4p

Product name:: micro male seat solder wire type usb socket with voltage rating 2A

Color:: Black/Silver

Operating temperature:: -25℃~75℃

Current Rating:: 2A

Voltage rating:: 30V

Operating force:: 0.7KG~3.57KG

Contact Resistance:: 30m Ohms Max

Insulation Resistance:: 100M Ohm/Min

Withstand Voltage:

500VAC

Product Name	micro male seat solder wire type usb socket
Model	A male
Life	3,000 times
Operating force	0.7KG~3.57KG
Temperature	-25℃—+75℃
Dielectric strength	500VDC
Rated current	2A
